Post mix juice machine Genesis Soalris
Post-mix soft drink/juice dispenser Genesis Solaris

A new generation of

post-mix juice dispenser machine

The post-mix juice dispenser Genesis Solaris offers maximum flexibility in all possible aspects. Enjoy your juice with a touch of a button. And with the integrated Cloud System you know what is happening with the machine at anytime.

Available for
Purchase

Cloud System      Exclusive Support       No Fees

Latest technologies

Everything you know it's here

Our machines always comes with the latest technologies that are suited for your needs and business.

Images of
drinks

More
Sales

Product
Images

15.6 HD
Display

BRIX
Measurement

Energy-
Efficient

RAUCH
Partners

RAUCH

Our collaboration with RAUCH Ho.Re.Ca (Bag in Box) proved to be highly successful, as our customers were extremely pleased with the quality of the juices they received.

User Interface

User Interface

Easy to use software makes it intuitive to change recipes, make adjustments and change different drinks.

Popular
Mobile Application

Mobile Application

Our mobile application for iOS and Android helps our customers to keep track of everything in the machine at anytime.

Designed for high-traffic locations

Designed for high-traffic locations

Peristaltic pumps are visible for easy access and maintenance. That way you can always stay up-to-date with the various drinks the market demands.

Post-mix juice dispenser Genesis Solaris
100% • Accurate

BRIX Measurment system

Highly accurate concentration measurements. It continuously determines the °Brix value of soft drinks, fruit juice, and syrup using advanced technology.

GENESIS SOLARIS

High quality materials meets the cloud.

Peristaltic pumps are visible for easy access and maintenance. The number of peristaltic pumps is usually four and can be configured up to six. And that's just the start.

Cloud system for duplex connection is based on the worldwide standards of best cloud computing software like Azure. This means the machine can send and receive all data needed for operation, maintenance, and analytical data structures.

Juice dispenser for soft drinks Solaris

15.6" Full HD Display

Beautiful 15.6 HD display navigate you throughout the easy to use software to prepare or edit drinks and more.

Stainless Steel

Stainless steel not only looks good but it's also very durable. Our machines always catches the eyes.

Cloud System

Cloud system for duplex connection is based on the worldwide standards of best cloud computing software

Top module

Genesis Solaris consists of 2 modules. Learn more about the top one.

Soft drink/juice dispenser Genesis Solaris advertisement of drinks

The Italian high-grade peristaltic pumps, the electrical power supply, and the water supply are made of high-quality material to ensure the effectiveness of the machine.

The number of peristaltic pumps is usually four and can be configured up to six.

Electronic management control system based on Linux OS makes Genesis Solaris your go-to machine. Custom designed software tailored for your specific business needs.

We use peristaltic pumps from this range:

  • Variable output flow ranges from 0.05 L/min to 1.2 L/min.
  • Mixing ratio - 1:5 to 1:29
  • Pump configurations from 2-3 rollers fixed or sprung or six rollers fixed.
  • Input/output push-in barb available on version ID4.8 ID6.4 or ID8.
  • Input/output screw-fit barb available, suitable for hoses from ID 3.2 to ID6.4.
  • Hoses and barbs are produced in materials suitable for contact with foods.
  • Compliant with RoHS directive 2011/65/EU

    For water supply by pump from operating range 3l(2.5 bar) up to 10l(0.5 bar).

Between the modules, there are hidden connections: electrical and tubes for fluids. These connections can be routed behind the countertop, or if drilling is possible, they can run directly through the countertop.

Dispensing of juice happens when juice and water are fed simultaneously in the mixing system located behind the display.

The machine include flow-metric system which is capable to achieve dissolving ratio in case of pressure variation. This can be done with 3 systems, such as pressure reduce valve, needle injection valve and flowmeter. Constant measuring of the flow of water give the machine ability to automatically adjust syrup concentrate just to precisely assure needed concentration.

Solaris can operate from 2 to 6 different concentrates (more can be added for particular circumstances).

Genesis Solaris also uses BRICKS System to accurately measure the concentrate and water being dispensed in each drink.

For flawless preparation/serving of drinks, this condition needs to be cleared.

  • Width: 390mm
  • Height: 490mm
  • Depth: 300mm
  • 15.6 Full HD Display
  • 10-point capacitive touch
  • WAN network connection
  • HDMI Interface
  • Energy-saving functions ✅
  • GSM Module ready-integration
  • Industrial level hardware by Renaissance processor, Amlogic ARM family processor
  • System for collecting wastewater and placement of cups
  • RGB Lights and more.
  • Variation of peristaltic pump from 90rpm to 200rpm
  • All stainless steel top module design

Bottom module

Learn more about the bottom module.

LINDR cooler for juice and soft drinks

Between the modules, there are hidden connections: Electrical and tubes for fluids. These connections can be routed behind the countertop, or if drilling is possible, they can run directly through the countertop.

Custom cooling systems which include various systems like two outputs/two outputs+one soda, three outputs, etc. You can use your own cooling system also!

Dispensing of juice happens when juice and water are fed simultaneously in the mixing system located behind the display.

The water source can be tap water or bottled water (from a 19L bottle), which is fed to the cooling unit, then to the hidden module for measurement, and finally to the mixing system in the top module.
